Please note: Some technical details are unavailable for this product

Technical Specifications

AttributeValue
Supply Voltage5 V dc
Output Type0.5 - 4.5 V
Maximum Operating Temperature85
Minimum Operating Temperature-30
IP RatingIP65
Mounting TypeThread Mount
Housing MaterialStainless Steel AISI 316L, Fluorocarbon FPM, Ceramic
ManufacturerTelemecanique Sensors
Series
Media MonitoredHydraulic Oil, Gas, Fresh Water, Air
Maximum Pressure Reading0 bar
Hazardous Area Certification
Calibrated
BrandTelemecanique Sensors
Accuracy %±0.5%
Communication Interface
Response Time2 ms
Process ConnectionG 1/4A
Pressure Type
For Use With
Maximum Switching Current5 mA
Pressure Reading Min-1 bar
Electrical Connection3-Pin Male Connector
