Technical Reference

Technical Specifications

AttributeValue
Supply Voltage10 V to 36 V
Output TypePNP
Maximum Operating Temperature70
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25
IP RatingIP65, IP67
Reverse Polarity ProtectionYes
Mounting TypeFlush
Thread SizeM12 x 1
Terminal Type4-Pin Connector
Housing MaterialBrass
Body StyleCylindrical
ManufacturerTelemecanique Sensors
Shape
Series
Hazardous Area Certification
Standards/Approvals
BrandTelemecanique Sensors
Supply Voltage DC Max36 V
Application
Communication Interface
Sensing Distance4 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current10 mA
Short Circuit Overload ProtectionYes
Length49.95
Switching Frequency Max2.5 kHz
Dimensions
Width17
Electrical Connection4-Pin Connector
