Technical Reference

Technical Specifications

AttributeValue
Mounting TypeFlush
Thread SizeM12 x 1
Terminal Type3-Pin M12 Connector
Housing MaterialBrass
Body StyleCylindrical
Supply Voltage10 V to 36 V
Output TypeNPN
Maximum Operating Temperature70
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25
IP RatingIP65, IP67
Reverse Polarity ProtectionYes
ManufacturerTelemecanique Sensors
Shape
Series
Hazardous Area Certification
Standards/ApprovalsUL Listed, CSA Certified, E2 Certified
BrandTelemecanique Sensors
Supply Voltage DC Max36 V
Application
Communication Interface
Sensing Distance4 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current10 mA
Short Circuit Overload ProtectionYes
Length37
Switching Frequency Max2.5 kHz
Dimensions
Width17
Electrical Connection3-Pin M12 Connector
