Technical Reference

Technical Specifications

AttributeValue
Supply Voltage10 V to 58 V
Output TypePNP
Maximum Operating Temperature70
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25
IP RatingIP69K, IP68
Reverse Polarity ProtectionYes
Mounting TypeNon-flush
Thread SizeM18 x 1
Terminal Type2m Cable, 3-Wire
Housing MaterialBrass
Body StyleCylindrical
ManufacturerTelemecanique Sensors
Shape
Series
Hazardous Area Certification
Standards/Approvals
BrandTelemecanique Sensors
Supply Voltage DC Max58 V
Application
Communication Interface
Sensing Distance12 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current10 mA
Short Circuit Overload ProtectionYes
Length63.5
Switching Frequency Max1 kHz
Dimensions
Width24
Electrical Connection3-Wire, 2 m Cable
