Technical Reference

Technical Specifications

AttributeValue
Mounting TypeNon-flush
Thread Size
Terminal Type4-Pin M12 Connector
Housing MaterialPBT
Body StyleRectangular
Supply Voltage20 V to 264 Vac/dc
Output Type
Maximum Operating Temperature70
Sensor TechnologyInductive
Shielding
Minimum Operating Temperature-25
IP RatingIP67
Reverse Polarity Protection
ManufacturerTelemecanique Sensors
Shape
Series
Depth80
Supply Voltage AC264 V
Hazardous Area Certification
Standards/Approvals
BrandTelemecanique Sensors
Supply Voltage DC Max264 V
Application
Communication Interface
Sensing Distance60 mm
Transducer Frequency
Accessory Type
For Use With
Switching Frequency
Switching Current10 mA
Short Circuit Overload Protection
Length80
Switching Frequency Max0.15 kHz
Dimensions80 x 40 x 80 mm
Width40
Electrical Connection4-Pin M12 Connector
