Technical Reference

Technical Specifications

AttributeValue
Mounting Type
Thread Size
Terminal TypeConnector M12 - 4 Pin
Housing MaterialPC
Body StyleRectangular
Standards Met
Output TypePNP
Maximum Operating Temperature55
Maximum DC Voltage24 V
Minimum Operating Temperature-25
IP RatingIP65
Detection Range1500 mm
ManufacturerTelemecanique Sensors
Optical TechnologyPhototransistor
Detection TypeRetro-reflective
Series
Sensor TypeCompact
Light SourceInfrared LED
Maximum Current100 mA
Hazardous Area Certification
Switching Mode
BrandTelemecanique Sensors
Communication Interface
Response Time0.3 ms
Electrical ConnectionM12 4 Pin Connector
