WAGO, 3.5mm Pitch, 12 Way, Pluggable Terminal Block, Plug, 713-1106

Technical Specifications

Attribute	Value
Housing Material	Glass fiber-reinforced Polyamide
Voltage (V)	160 V
Minimum Wire Size (AWG)	28
Maximum Wire Size (mm²)	1 mm²
Standards/Approvals	RoHS
Number of Rows	2
Connector Gender	Female
Depth	16
Width	22.5
Current (A)	10 A
Length	18.8
Minimum Wire Size (mm²)	0.25 mm²
Series	713
Pitch (mm)	3.5 mm
Product Type	Pluggable Terminal Block
Maximum Wire Size (AWG)	16
Colour	Black
Wire Connection Method	Push-in CAGE CLAMP
Orientation	Straight
Number of Contacts	12
